800kg Stackable Metal Wire Container for Wine Bottles – HM-WEU001
This heavy-duty wire mesh container is specifically engineered for the wine industry, offering a robust solution for storage and logistics. With a loading capacity of 800 kg and stackability of 4+1 high, it maximizes vertical space in cellars and distribution centers. Constructed from mild steel Q235 and available in zinc, hot-dip galvanized, or powder coating finishes, it ensures durability and corrosion resistance in demanding environments.
Key Selling Points
- High Loading Capacity: Supports up to 800 kg per container, allowing dense storage of heavy wine bottles.
- Space Optimization: Stackable up to 4+1 high, significantly increasing vertical storage density in warehouses.
- Bottle Protection: Specialized grid size (55x113 mm) holds Bourgogne bottles securely, minimizing movement and breakage.
- Corrosion Resistance: Available in zinc, hot-dip galvanized, or powder coating finishes to withstand humid cellar conditions.
- Efficient Logistics: Optimized for 1x40'HQ containers, loading 332 sets to reduce shipping costs.
Technical Specifications
| Model | HM-WEU001 |
| Exterior Dimensions (LxWxH) | 1140 x 830 x 980 mm |
| Wire Gauge | 5 - 12 mm |
| Grid Size | 55 x 113 mm |
| Loading Capacity | 800 kg |
| Stackability | 4 + 1 high |
| Finish | Zinc / Hot-dip galvanized / Powder coating |
| Material | Mild Steel Q235 |
| Bottle Capacity | 500 PCS Bourgogne Bottles |
| Container Loading | 332 sets per 1x40'HQ |
Models and Options
The standard model is HM-WEU001. Customization options for dimensions, finishes, and internal partitions are available upon request.
Materials and Structure
Constructed from high-strength mild steel Q235, this container features a robust wire mesh structure with a grid size of 55x113 mm. The wire gauge ranges from 5 to 12 mm, providing a balance of strength and weight. The container is designed for four-way forklift entry and features a half-drop gate for easy access.
Applications
- Industrial wineries for bottle aging (sur latte) and storage.
- Large-scale wine cellars and bonded warehouses.
- Wine logistics and distribution centers for high-volume handling.
- Global wine export/import operations.
Customization
We offer customization in dimensions, wire gauge, finish, and optional internal padding or partitions to meet specific bottle types and operational needs.
Case Study
Our wine containers have been successfully deployed in automated cellar upgrades, transitioning from manual stacking to mechanical rack-based storage. In cross-border logistics projects, they ensure secure, vibration-resistant container loading for international sea freight. These containers have helped clients reclaim up to 70% of floor space compared to traditional pallet stacking.
FAQ
What is the lead time for HM-WEU001?
Please contact our sales team for current lead times based on order quantity and customization.
Can this container be used for Champagne bottles?
The standard model is optimized for Bourgogne bottles, but with customization it can be adapted for Champagne or Bordeaux bottle shapes.
What finishes are available for corrosion protection?
We offer zinc plating, hot-dip galvanizing, and powder coating to suit different environments, especially high-humidity cellars.
How many containers fit in a 40-foot container?
332 sets can be loaded in a 1x40'HQ container, maximizing shipping efficiency.
Is the container collapsible for return logistics?
Yes, the design includes a collapsible feature for flat folding, providing a 4:1 return ratio.
Can the container be handled by forklift?
Yes, it features four-way forklift entry for easy mechanical handling.
Inquiry Information
For pricing, MOQ (1x20GP), and delivery options, please contact:
MARY KONG
Email: mary@net-railing.com
Tel/WhatsApp: +86 150 4058 7228
Phone: +86 411-3981 3061
